Syscal Kid Switch 단채널 수동탐사 장비 Syscal Kid Switch Resistivity sounding and profiling sysyem
-내장형 SwitchBox로 편리
-다양한 전기 탐사 배열 이용 가능
-전기비저항, IP, SP 탐사 활용 가능
-Syscal 제품군 중 가장 컴팩트
Information
| <<Transmitter>> | |
|---|---|
| Voltage | 0 - 400 Vpp |
| Current | 0 - 500 mA |
| Power | Auto controled Internal 25W DC/DC converter |
| Battery | internal battery or external 12V |
| <<Receiver>> | |
| Pulse duration | 0.5s, 1s, 2s |
| Channels | 1 channel 24 switches |
| Input Impedance | 22 MOhms |
| Input Voltage | 2.5V, automatic gain, input protection 200V |
| Resolution / Accuracy | 1 µV / 0.2% |
| Readings | Resistivity, Self potentiel, Induced polarisation,Quality control |
| Noise Rejection | power line rejection, SP linear drift correction. |
| Storage | 1400 readings, stored on solid state memory |
| <<Dimensions>> | |
| ( L x W x H) | 23x18x23cm Fiber glass casing, weather proof, |
| weight | 4.7Kg with internal RX, TX batteries |
| Operating Temp. | -10 to +50°C |
