Information
| Absolute Calibration | ± 5% in air traceable to NIST |
|---|---|
| Sensitivity | Typically 4 μA per 1,000 μmol s-1 m-2 in water |
| Linearity | Maximum deviation of 1% up to 10,000 μmol s-1 m-2 |
| Response Time | 10 μs |
| Temperature Dependence | ± 0.15% per °C maximum |
| Cosine Correction | Optimized for underwater and atmospheric use |
| Azimuth | < ± 1% error over 360° at 45° elevation |
| Operating Temperature Range | −40 °C to 65 °C |
| Detector | High stability silicon photovoltaic detector (blue enhanced) |
| Sensor Housing | Corrosion resistant metal with acrylic diffuser for both saltwater and freshwater applications. Waterproof to withstand approximately 5500 kPa, 560 meters (800 psi). |
| Size | 3.18 cm diameter × 4.62 cm height (1.25” × 1.81”) |
| Weight | 227 g (8 oz) |
| Mounting | Three 6-32 holes are tapped into the base for use with the 2009S Lowering Frame or other mounting devices |
| Cable | Requires 2222UWB Underwater Cable (available in 3, 10, 30, 50, 100 meter lengths) |
| 품질보증기간 | 2년 + 1년 연장 |
